Description

Takeoff Weight

246 g

‌Standard aircraft weight (including the Intelligent Flight Battery, propellers, and a microSD card). The actual product weight may vary due to differences in batch materials and external factors. Training or examination is not required for flying this product in most countries and regions. Always check local laws and regulations before use.‌‌‌‌‌

Dimensions

Folded (without propellers): 138×81×58 mm (L×W×H)

Unfolded (with propellers): 245×289×56 mm (L×W×H)

Max Flight Distance

15.7 km

Max Ascent Speed

5 m/s

Max Descent Speed

3.5 m/s

Max Horizontal Speed (at sea level, no wind)

16 m/s

The max horizontal speed is subject to dynamic local restrictions. Please abide by local laws and regulations when flying.

Max Takeoff Altitude

4000 m

2000 m when taking off with propeller guards.

Max Flight Time

31 minutes

Measured in a controlled test environment. Specific test conditions are as follows: flying forward at a constant speed of 17 kph in a windless laboratory environment, in photo mode (without photo taking operation during flight), and from 100% battery level until 0%. Results may vary depending on the environment, actual use, and firmware version.

Max Wind Speed Resistance

10.7 m/s (Level 5)

Max Pitch Angle

40°

Operating Temperature

0° to 40° C (32° to 104° F)

Global Navigation Satellite System

GPS + GLONASS + Galileo

Hovering Accuracy Range

Vertical:

±0.1 m (with vision positioning)

±0.5 m (with GNSS positioning)

Horizontal:

±0.3 m (with vision positioning)

±1.5 m (with GNSS positioning)

Internal Storage

N/A

Class

C0 (EU)

Image Sensor

1/2.3-inch CMOS, Effective Pixels: 12 MP

Lens

FOV: 83°

Format Equivalent: 24 mm

Aperture: f/2.8

Focus: 1 m to ∞

ISO Range

Video:

100-3200

Photo:

100-3200

Shutter Speed

Electronic Shutter: 4-1/8000 s

Max Image Size

4000×3000

Still Photography Modes

Single Shot: 12 MP

Timed: 12 MP

JPEG: 2/3/5/7/10/15/20/30/60 s

JPEG + RAW: 5/7/10/15/20/30/60 s

Automatic Exposure Bracketing (AEB): 12 MP, 3 frames at 2/3 EV step

Panorama: Sphere, 180°, and Wide Angle

Photo Format

JPEG/DNG (RAW)

Video Resolution

2.7K: 2720×1530@24/25/30 fps

FHD: 1920×1080@24/25/30/48/50/60 fps

Video Format

MP4 (MPEG-4 AVC/H.264)

Max Video Bitrate

40 Mbps

Supported File System

FAT32 (≤ 32 GB)

exFAT (> 32 GB)

Digital Zoom

2.7K: 3×

FHD: 4×

Color Mode

Normal

QuickShots Modes

Dronie, Helix, Rocket, Circle, and Boomerang

Stabilization

3-axis mechanical gimbal (tilt, roll, and pan)

Mechanical Range

Tilt: -110° to 35°

Roll: -35° to 35°

Pan: -20° to 20°

Controllable Range

Tilt:

-90° to 0° (default)

-90° to 20° (extended)

Max Control Speed (tilt)

100°/s

Angular Vibration Range

±0.01°

Downward

Precise Hovering Range: 0.5-10 m

Operating Environment

Downward:

surfaces with discernible patterns, diffuse reflectivity >20% (e.g., walls, trees, people), and adequate lighting (lux >15)

Video Transmission System

DJI O2

Live View Quality

Remote Controller:

720p/30fps

Operating Frequency

2.400-2.4835 GHz

5.725-5.850 GHz

Transmitter Power (EIRP)

2.400-2.4835 GHz:

< 26 dBm (FCC)

< 20 dBm (CE/SRRC/MIC)

5.725-5.850 GHz:

< 26 dBm (FCC/SRRC)

< 14 dBm (CE)

Max Transmission Distance (free of interference)

FCC: 10 km

CE: 6 km

SRRC: 6 km

MIC: 6 km

Measured in an unobstructed outdoor environment free of interference. The above data shows the farthest communication range for one-way, non-return flights under each standard. During your flight, please pay attention to RTH reminders in the DJI Fly app.

Max Transmission Distance (with interference)

Strong Interference: urban landscape, approx. 1.5-3 km

Medium Interference: suburban landscape, approx. 3-6 km

Low Interference: suburb/seaside, approx. 6-10 km

Data tested under FCC standard in unobstructed environments with typical interference. Used for reference purposes only and provides no guarantee for actual flight distance.

Lowest Latency

Approx. 200 ms

Depending on the actual environment and mobile device.
